CFDI 4.0 XML Requirements: Mandatory Fields & Validation Rules Explained

Mexico's CFDI 4.0 XML schema contains over 100 data fields with strict validation rules enforced by SAT through the PAC certification process. The most common rejection cause is RFC-name mismatch — the receiver's legal name must match SAT records character-for-character, including accent marks and legal entity suffixes.

What Is the CFDI 4.0 XML Structure?

the CFDI 4.

The CFDI 4.0 XML follows a hierarchical structure defined by SAT's Anexo 20 technical specification:

• cfdi:Comprobante (Root): Version, date, payment method, currency, total amounts, export flag
• cfdi:Emisor (Issuer): RFC, legal name, fiscal regime
• cfdi:Receptor (Receiver): RFC, legal name, fiscal regime, postal code, Uso CFDI
• cfdi:Conceptos (Line Items): Product/service code (ClaveProdServ from SAT catalog), unit code, description, quantity, unit price, amounts
• cfdi:Impuestos (Taxes): IVA rates, ISR withholdings, IEPS where applicable
• cfdi:Complemento (Supplements): Optional structured extensions like Complemento de Pago, Nómina, Comercio Exterior
• tfd:TimbreFiscalDigital: SAT's digital stamp added by the PAC after certification

What Are the Most Critical Validation Rules?

RFC Validation (New in CFDI 4.0)

CFDI 4.0 validates both issuer and receiver RFC against SAT's Lista de Contribuyentes:

• The RFC must be active (not cancelled or suspended)
• The legal name (Nombre) must match SAT records exactly — including accents (é, ñ), legal suffixes (S.A. de C.V., S.C.), and spacing
• The receiver's fiscal regime must match their SAT registration
• The receiver's postal code must match their registered fiscal domicile

ClaveProdServ (Product/Service Code)

Every line item must include a ClaveProdServ code from SAT's catalog of ~52,000 product and service codes. Common errors:

• Using deprecated codes from previous catalog versions
• Selecting overly generic codes that trigger SAT review flags
• Mismatching the code with the actual product/service description

Uso CFDI Validation

The Uso CFDI field indicates the receiver's intended tax deduction purpose. In CFDI 4.0, this must be compatible with the receiver's fiscal regime:

Uso CFDI Code	Description	Valid Regimes
G01	Adquisición de mercancías	601, 603, 606, 612, 620, 621, 622, 623, 624, 625, 626
G03	Gastos en general	All regimes
I01	Construcciones	601, 603, 606, 612, 620, 621, 622, 623, 624, 625, 626
S01	Sin efectos fiscales	All regimes — use when receiver won't deduct

Common CFDI 4.0 Rejection Errors

Common CFDI 4. 0 Rejection Errors — CFDI33105: Receiver RFC not found in SAT database — Verify RFC spelling and that receiver is registered.

Error	Cause	Solution
CFDI33105	Receiver RFC not found in SAT database	Verify RFC spelling and that receiver is registered
CFDI33106	Receiver name doesn't match SAT records	Request exact legal name from receiver's Constancia de Situación Fiscal
CFDI40101	Uso CFDI incompatible with receiver's regime	Verify regime code with receiver before issuing
CFDI40103	Receiver postal code doesn't match fiscal domicile	Use the 5-digit postal code from receiver's SAT registration
